Voltige+ 723 Commercial Elevator

Description

Whether you are an architect, general contractor or real estate developer, the overall offering of this elevator will be easy to integrate into the development and implementation of your project with an ease of use. The Voltige+ passenger elevator is equipped with reliable and easy-to-maintain technologies. Can be installed in a new construction or an existing building, this elevator is designed for buildings of 2 to 5 floors such as condo buildings, rental buildings or office buildings.

Technical Specifications

Device type: Elevator / Commercial

Model: EL-703 Voltige+

Applicable standard: CSA-B44-19

Trajectory: Maximum 40’ (12,192 mm). Calculated from the lower floor to the top floor

Maximum capacity: Maximum 2500 lb (1134 kg)

Cabin dimensions: Maximum 25‘2 (2.32 m2) . Possibility of various sizes.
Maximum 54" X 80" (1 372 mm X 2032 mm)
**Dimensions on request**

Cabin height: 86’ (2184 m)

Doors: Two-speed automatic sliding doors with stainless steel finish. Clear opening: 36" (914 mm) x 84-5/8" (2149.475 mm)

Drive System: Hydraulic cylinder and cables

Travel speed: Maximum 100 ft/min (0.5 m/sec).
Smooth start and stop (Soft-start/Soft-stop).

Advantages

  • Custom design and service
  • Easy to use
  • Proven technologies
